Engineering Division Lubricants Supplies Metal Services Administration
Steel products Tubes Products

METAL DIVISION

Steel Tubes and Pipes


The Warefield Engineering Limited

38 Johnson Road, Heston, Middlesex

TW5 9LJ, Great Britain

Tel: (+44) 0208 759 1600  Fax: (+44) 0208 897 7608  Email: info@warefield.co.uk

We are suppliers of West European origin steel pipes & tubes for most requirements from manufacturing, oil and gas, chemical and power sectors. We supply the material to BS, Din, ASTM specifications in carbon, alloy and stainless steel. We can also have the tubes & pipes profiled to your drawings.


We supply metal tubes in round and square. We can also supply, in selected sizes and material only, D shaped as well omega or with single fin on either side of the tube/pipe.

Supply Program for

Boiler & heat exchanger tubes

Seamless & welded



The popular sizes and specs are always carried in stock. The rest are made to order with shortest delivery times.


Origin: West Europe


Heat Exchanger Tubes

Stock list Contains Tubes in the Following Grades


A178/A178M-02

 Standard Specification for Electric-Resistance-Welded Carbon Steel and Carbon-Manganese Steel Boiler and Superheater Tubes

A179/A179M-90a(2001)

 Standard Specification for Seamless Cold-Drawn Low-Carbon Steel Heat-Exchanger and Condenser Tubes

A192/A192M-02

 Standard Specification for Seamless Carbon Steel Boiler Tubes for High-Pressure Service

A210/A210M-02

 Standard Specification for Seamless Medium-Carbon Steel Boiler and Superheater Tubes

A214/A214M-96(2001)

 Standard Specification for Electric-Resistance-Welded Carbon Steel Heat-Exchanger and Condenser Tubes

BS 3059-1:1987

 Welded Steel boiler and superheater tubes 1


BS 3606 : 1992


Steel tubes for heat exchangers

 DIN 2448/17175,  in material   St35.8/10CrMo910/ 15NiCuMoNb5 (WB36)/ 13CrMo44/X20CrMoV121

Seamless boiler tubes

PRODUCTS


Click on the following for further details

Supply Program for
CARBON STEEL TUBES & PIPES
CONSTRUCTION:   Seamless, Welded
ORIGIN:                    European mills

The Warefield Engineering Limited supply carbon steel pipe both welded and seamless in sizes from 1/2" to 36", supplied by "world-class" domestic and overseas pipe mills.

We sells over 50 pipe and round tubing sizes covering three major production process: Electric Resistance Welded; Furnace Butt Welded (or Continuous Welded) and Seamless Pipe.

End user industries includes: Oil and gas, construction, water well, fire protection, landscaping, waste treatment, power generation, refining and pharmaceutical.

STEEL GRADES
DIN 1629- St 37.0; St 52.0;  DIN 2440  St 33.0 ; DIN 2441 St 33.0 ; DIN 2470(2) / 17172
EURONORM: EN 10210-1/2 -S235JRH ; EN 10210-1/2 - S355J2H
API: API 5 L Gr. B; Gr. X 52
ASTM / ASME: A/SA 106-Grade B and ASTM A 530M / SA530M; A/SA 333 Gr 6 ; A/SA 335 Gr P11
ASTM: A53 Gr. F

We can also supply precision tubes in the following BS grades
BS 3601/1974 CFS320. CFS360 CFS410
BS 3602/1978 Part 1 CFS360. CFS 410
BS 3603/1977 CFS410 LT50
BS 3604/1978 CFS620
BS 3606/1978 CFS320 CFS620, CFS440
BS 6323/1982 Part 4 CFS3, CFS4, CFS8

DIN specs
DIN 2391 Part I, Part 2 ST 30, ST 35, ST45

ALLOY STEEL TUBES & PIPES

Alloy Steel Grades

chromium-molybdenum deep hardening steel


SIZE:

Sizes up to OD 12" and available in random lengths

ORIGIN:

European origin material only


Supply Program for

STAINLESS STEEL TUBES & PIPES

CONSTRUCTION:   Seamless, Welded

ORIGIN:   European mills

INDUSTRY:  Chemical, Oil & Gas, Aviation, Food

SIZES:   Seamless up to 6" OD (152mm); Welded: 32" OD (812.8mm)

MATERIAL:  Duplex, Ferritic/Austenitic Stainless Steel

SPECIAL:   904L (1.4539) - This steel was specifically developed for sulphuric acid use and can    be used across the whole concentration range up to 35 deg C.



Steel name

Steel number

AISI

BS

Ferritic stainless steels




X3CrTi17

1.451

439


X2CrMoTi18-2

1.4521

444


X6CrMoNb17-1

1.4526

436


X2CrNi18-9

1.4307

304L

304S11

X6CrNiTi18-10

1.4541

321

321S31

X6CrNiNb18-10

1.455

347

347S31

X2CrNiMo17-12-2

1.4404

316L

316S11

X6CrNiMoTi17-12-2

1.4571

316Ti

320S31

X6NiCrSiNCe35-25

1.4854



X2CrNiN23-4

1.4362



X1CrNi25-21

1.4335

310L


X1CrNiMoN25-22-2

1.4466

310MoLN


X1NiCrMoCu31-27-4

1.4563



X1NiCrMoCu25-20-5

1.4539



STAINLESS STEEL GRADES

Shaped tubes
Carbon steel tubes (for boiler and other application) with fin on either side like a wing  or lip (or boiler membrane walls ) is available on selected sizes and materials. Please ask within.

STEEL GRADES

ASTM

WE CAN SUPPLY MOST GRADE FROM THE FOLLOWING ASTM

A53-94

PIPE, STEEL, BLACK AND HOT-DIPPED, ZINC COATED

A105

CARBON STEEL, FORGING STEEL

A106

SEAMLESS, CARBON STEEL, HIGH TEMPERATURE

A179

SEAMLESS LOW CARBON STEEL FOR REFINERY

A192

SEAMLESS CARBON STEEL BOILER TUBE

A213

SEAMLESS, ALLOY STEEL, HEAT EXCHANGER

A252

WELDED AND SEAMLESS STEEL PIPE

A334

SEAMLESS AND WELDED CARBON TUBE

A512

COLD DRAWN BUTT WELD CARBON STEEL

A513

WELDED CARBON AND ALLOY STEEL TUBE

A 312

STEEL PIPES AND TUBES

A316 L

STEEL PIPES AND TUBES

A269

STEEL PIPES AND TUBES

API

A, X42, X52, X56, X65, ELECTRIC WELDED STEEL PIPES

ASTM A53

TYPE 5 GRADE A GRADE B, Mechanical Tubes,

ASTM A106

GRADE A GRADE B, Mechanical Tubes,

ASTM A 161

Mechanical Tubes,

ASTM A179

Mechanical Tubes,

ASTM A192

Mechanical Tubes,

ASTM A210

GRADE Al Mechanical Tubes,

ASTM A213

GRADE T12 Mechanical Tubes,

ASTM A333

GRADE 1 GRADE 6 Mechanical Tubes,

ASTM A334

GRADE 1 GRADE Mechanical Tubes,

ASTM A335

GRADE P12 Mechanical Tubes,

ASTM A519

GRADES MT 1010. MT 1015 MT 1020 1008 Mechanical Tubes,

ASTM A523

GRADE A GRADE B, Mechanical Tubes,

ASTM A556

GRADE A. GRADE B Mechanical Tubes,

ASTM A795

TYPE 5 GRADE A GRADE B Mechanical Tubes,

ASTM A822

Mechanical Tubes,

A-178A

BOILER TUBE, ERW

SA-210,

A1, C, SEAMLESS BOILER TUBES

SA 213

SEAMLESS BOILER TUBES IN GRADES, T2 T11 T22 T5 T9, T91

SA-213

BOILER TUBE, STAINLESS STEEL IN GRADES, TP-304 TP-304H TP-316

TP-316H TP-321 TP-321H TP-347 TP-347H


BS

OUR SUPPLY INCLUDES MOST BS GRADES FROM THE FOLLOWING SPECS.

BS 3059

BOILER STEEL TUBES

BS 3601

CARBON STEEL PIPES, PRESSURE PURPOSE

BS 3602

STEEL PIPES, PRESSURE PURPOSE

BS 3606

STEEL TUBE FOR HEAT EXCHANGER

BS 6323

SEAMLESS AND WELDED TUBES FOR AUTOMOBILE/MECHANICAL

BS980

BS980 1950, CDS1, CDS2, CDS3, 4CDS, CDS8

304, 304H, 304L,

STAINLESS STEEL PIPES AND TUBES

321 & 321H

STAINLESS STEEL PIPES AND TUBES

316, 316L, 316H

STAINLESS STEEL PIPES AND TUBES

6 Moly Type


ALLOY

ALLOY-20, ALLOY-28, ALLOY-600, ALLOY-625, ALLOY-800, ALLOY-800H, ALLOY-825,

NICKEL-200, ALLOY-201, ALLOY-400,

HASTELLOY

HASTELLOY B2, HASTELLOY-C276, HASTELLOY-G3

DUPLEX

DUPLEX AND SUPER DUPLEX, HIGH STRENGTH ALLOY

CUPRO/NICKEL

CUPRO/NICKEL 70/30 AND 90/10

BS4127: 1994

STAINLESS STEEL TUBES

BS 980/ 1950

Mechanical Tubes, CDS1, CDS 2 CDS 3, CDS 4, CDS 8

BS3059 1987

Part 1 CFS 320 Mechanical Tubes,

BS 3053 1979 Part 2

CFS360. CFS 440. CFS620 Mechanical Tubes,

BS 3601/1974

CFS320. CFS360 CFS410 Mechanical Tubes,

BS 3602/1978

Part 1 CFS360. CFS 410 Mechanical Tubes,

BS 3603/1977

CFS410 LT50 Mechanical Tubes,

BS 3604/1978

CFS620 Mechanical Tubes,

BS 3606/1978

CFS320 CFS620, CFS440

BS 4568/1970 Part 1

Mechanical Tubes,

BS 5045/ 1982 Part 1

Mechanical Tubes,

BS 6323/1982 Part 4

CFS3, CFS4, CFS8 Mechanical Tubes,


DIN

FOLLOWING DIN SPECS AND MOST OF THEIR GRADES ARE SUPPLIED BY US.

Din 1615

WELDED UNALLOYED STEEL TUBE

Din 1626

NON-ALLOY CIRCULAR WELDED TUBE

Din 1629

NON-ALLOY CIRCULAR SEAMLESS TUBE

Din 17120

WELDED CIRCULAR STEEL TUBE

Din 17172

STEEL PIPE FOR PIPE LINES

Din 17173

SEAMLESS, LOW TEMPERATURE

Din 17175 St.35

SEAMLESS FOR ELEVATED TEMPERATURES

Din 17177

ELECTRIC RESISTANCE WELDED TUBE

Din 17457

WELDED STAINLESS STEEL PIPE

Din 2391

SEAMLESS PRECISION STEEL TUBE

Din 2394-81

WELDED PRECISION STEEL TUBE

Din 2462

STAINLESS STEEL SEAMLESS TUBE

Din 17456 & Din 17458

W. Nr. 1.4301, 1.4306, 1.4541, 1.4571, 1.4401, 1.4404, 1.4436, 1.4435

Din 17457

WELDED STAINLESS STEEL TUBES

Din  St

St37, St44, St52, St56, StE385.7TM, StE445.7TM, ELECTRIC WELDED CARBON STEEL PIPES FOR OIL AND GAS.
Hydraulic Tubes / Precision Tubes

Hydraulic tubes / precision tubes in a comprehensive range and in corrosion resistant material from stainless steels, nickel alloys and titanium tubing grades is supplied by us. All sizes are supplied in tight dimensional tolerances and with smooth surfaces to reduce the risk of leakages. We can supply hydraulic tubes in thin wall.

We offer hydraulic tubes up to 50mm in OD and in 3 & 6 meter lengths. We also cut to length to your requirement. We can supply these tubes with caped (plugged ends to reduce the risk of any contamination.

The supply includes the Seamless Steel Hydraulic Tubing under specification SAE J524, ASTM / ASME / SA / A179 .
